PPD71
Dimension 30(W) × 30(H) × 28(D) [mm] Supply voltage DC5V±10% Detectable size Over 0.5μm(approx.) Detectable range 0 to 500μg/m3 Light source LED Output method UART Ripple No limitation Operating temp. & humidity -10 to 60ºC, below 95%rh Storage temp. & humidity -25 to 70ºC, below 95%rh Initial stabilization time 60 seconds after power is supplied. Light Souse Life time 7 years Power consumption Below 100mA Detection method Auto-suction by a built-in heater resistor Maintenance Possible Reference TSI DUSTTRACK II 8530
![](https://www.estcorp.com.tw/wp-content/uploads/2018/04/PPD71-2-903x1024.png)
![](https://www.estcorp.com.tw/wp-content/uploads/2018/04/PPD71-1-984x1024.png)
